2 Channel Dj Power Amplifier 3400 Watts (2ohm) Model ATI 12
2 Channel Dj Amplifier 5400 Watts (2ohm) Model ATI 20
2 Channel Dj Amplifier 4600 Watts (2ohm) Model ATI 18+
| Model | ATi 18 | |
| 8Ω stereo power | 1250W x2 | |
| 4Ω stereo power | 1725W x2 | |
| 2Ω stereo power | 2300W x2 | |
| 8Ω Bridge Mono power | 3450W | |
| 4Ω Bridge Mono power | 4600W | |
| Frequency Response(+/-0.1db) | 20Hz-20kHz +-0.5dB | |
| Signal Noise Ration(dB) | ＞80dB | |
| THD+N（8OHM 1KHZ IN 1/4 OUTPUT) | ＜0.05% | |
| Damping Factor(8OHM 1K) | ＞800 | |
| Slew Rate | ＞20V/us | |
| Output Topology | Class H | |
| Input connectors(per ch.) | 3-pin XLR, electronically balanced | |
| Link connectors(per ch.） | XLR, 3 pin male | |
| Input Impedance | 20kΩBALANCED-10kΩUNBALABCED | |
| Amplifier Protection | Protection of short circuit, open circuit, overheat, overload, DC, super sonic frequency etc. | |
| Dimension(CM) | 3U:67.5x57x21.5cm | |
| Net Weight | 40 Kgs | |
| Gross Weight | 41.5 Kgs |
