2 Channel Power Amplifier 7200 Watts (2ohm) Model ATI 30+
2 Channel Power Amplifier 8400 Watts (4ohm) Model ATI 50+
2 Channel Power Amplifier 7200 Watts (4ohm) Model ATI 40+
| 8Ω stereo power | 2x1800W | |
| 4Ω stereo power | 2x3600W | |
| 8Ω Bridge Mono power | 4800W | |
| 4Ω Bridge Mono power | 6400W | |
| Signal Noise Ration(dB) | ＞80dB | |
| THD+N（8OHM 1KHZ IN 1/4 OUTPUT) | ＜0.05% | |
| Damping Factor(8OHM 1K) | ＞2000 | |
| Slew Rate | ＞20V/us | |
| Input sensitivity | 0.775v/1.0v/1.4v | |
| Output Circuit | Class H++ | |
| Frequency Response(+/-0.1db) | 20Hz-20kHz +-0.5dB | |
| Input connectors(per ch.) | 3-pin XLR, electronically balanced | |
| Link connectors(per ch.） | XLR, 3 pin male | |
| Input Impedance | 20kΩBALANCED-10kΩUNBALABCED | |
| Output Connectors | NEUTRIK | |
| Amplifier Protection | Protection of short circuit, open circuit, overheat, overload, DC, super sonic frequency etc. | |
| Transport Dimension(CM) | 3U:67.5x57x22.5cm | |
| Net Weight | 42gs | |
| Gross Weight | 47gs |
